TECHNICAL PARAMETERS |
Test principle | Test principle of chemistry items: Photoelectric colorimetry.Test principle of physical and chemical items: Refraction method,
transmittance absorbance. |
Test items | Urobilinogen (UBG), bilirubin (BIL), ketone body (KET), blood
(BLD), protein (PRO), nitrite (NIT), leukocyte (LEU), glucose
(GLU),
pH value (pH), specific gravity (SG), vitamin C (VC) (optional),
microalbumin (MALB) (optional), creatinine (Cr) (optional) and
urinary calcium (Ca) (optional). |
Physical and chemical test items | Specific gravity (optional), turbidity (optional), color (optional)
and conductivity (optional). |
Test speed | 240 samples/ hour |
Sample type | Urine |
Sample volume | Chemistry analysis item: Min. volume: 1.6mL non-centrifuged urine;
aspiration volume: about 0.6mL; Chemistry analysis item +
physical and chemical item: Min. volume: 3.0mL non-centrifuged
urine; aspiration volume: about 2.0mL. |
Volume of sample to be tested | 60 samples. The volume can be extended to 320 samples if
pre-storage tray and reclaiming tray modules are installed. |
Volume of strip bin | A single strip bin holds at least 300 strips |
Maximum capacity of waste strip bin | 400 strips |
Temperature and humidity monitoring function of strip bin | It has internal temperature and humidity monitoring function and it
will alarm if they exceed the set range. |
Strip carrying stability | 3 days |
STAT function | Special STAT position, available for sample test at any time |
Sample barcode identification | Built-in barcode reader (laser), sample barcode can be read
automatically An external barcode reader (red light),manual
scanning
of barcode (optional). |
LIS port | Serial port LIS |
Connection with LIS system | Bidirectional communication with LIS system is supported |
Test results storage capacity | Not less than 100,000 pieces of data |
Weight | 67kg; 102kg if pre-storage tray and reclaiming tray modules are
installed |
Power | 200 VA |
Size (L×W×H) | 680 mm×700 mm×590 mm 1360 mm×900 mm×590 mm if pre-storage trayand
reclaiming tray modules are installed |
Ambient temperature | 10 ~30 ℃ |
Relative humidity | below 70% |
Atmospheric pressure | 75kPa~106kPa |
Supply voltage | 100-240V~ 50/60Hz |
Intensity of light | prevent direct sunlight |
