Clinical Laboratory Medical Equipment Fully Automatic Chemistry Analyzer 340nm

Product Categories

Hefei DX Medical Co., Ltd.

Contact Now

Ask Lasest Price
Brand Name :	GH
Model Number :	CS-T180
Certification :	CE
Price :	1
Payment Terms :	L/C, D/A, D/P,T/T, Western Union, MoneyGram
Supply Ability :	50000
Delivery Time :	7

Add to Cart

New Laboratory Equipment Clinical fully automatic chemistry Analyzer

Overview

Quick Details

Supply Ability

Packaging & Delivery

TECHNICAL PARAMETERS
Throughput	Colorimetric items: Constant-speed 180 tests/ hour, ISE items (optional): Maximum 540 tests/ hour.
Wavelengths	340nm, 380nm, 405nm, 450nm, 480nm, 505nm, 546nm, 570nm, 600nm,660nm, 700nm, 800nm.
Reaction temperature	37±0.1℃
Test method	1-point endpoint assay, 2-point endpoint assay, 2-point rate assay, rate A assay
Reagent and sample position	Maximum 80 reagent/sample positions, with refrigeration
Reagent volume	10μL~300μL, step 0.1μL
Sample and reagent cooling system	2℃～12℃
Volume of reagent bottle	20mL,35mL,70mL
Barcode recognition system	1 built-in bar code reader (optional)
Probe liquid level sensor	Integrated with probe
Sample type	Serum, plasma, urine, ascites, cerebrospinal fluid
Sample volume	2μL~35μL, step 0.1μL
Specifications of test tube	Φ12mm×75mm, Φ12mm×100mm, Φ13mm×75mm, Φ13×100mm. Standard cup, original blood collection tube.
Cuvette type	Discrete type, plastic
Optical path of cuvette	5mm
Reaction position	8 sets, 7 for each set, totally 56 positions
Reaction time	13min
Reaction solution volume	100μL～360μL
Light source	20W/12V quartz-halogen lamp with a long service life
Absorbance range	0~5.7Abs
Absorbance linear Range	0~3.5Abs
Power voltage	100V-240V~ 50/60Hz
Environmental temperature	15℃ ~32℃
Relative humidity	Not greater than 75%
Atmospheric pressure	75kPa~106kPa
Weight	100kg
Boundary dimension (mm)	744×703×530(L×W×H)
Rated power	600VA

Clinical Laboratory Medical Equipment Fully Automatic Chemistry Analyzer 340nm
