USB WIFI Types Portable Color Doppler Wireless Ultrasound Machine/Probe Convex+Linear+Cardiac GH G10RL
Wireless Color doppler Ultrasound Technical Specifications
This types machine is 3 in 1 probe , include the convex +linear+cardiac probe. No need change the probe head , only change from the software , then you can realize change the probe .
In this way ,change probe will have no hurt for the machine . more easy and convenient to use !
Features:
| Probe | convex+linear+cardiac |
| Frequency | convex probe : 3.5/5.0mhz linear probe :7.5/10mhz cardiac probe :3.5/5.0mhz |
| Depth | convex probe:90-305mm linear probe:20-80mm cardiac probe:90-160mm |
| Host | IOS Android and windows |
| Connection | 802.11.n WIFI(AP) |
| Playback frames | 100, 200, 500, 1000 optional |
| Throughout | 150Mbit/s |
| Field of view | 80 degree |
| Display mode | B, B/M, color, PW, PDI |
| Image gray scale | 256 level |
| channel | 64 |
| Frame | 24s/f |
| Gain | 40-110Db |
| Language | English, Chinese,Russian, German, Italian, Spanish, Portuguese |
| Power | by built-in battery |
| Power consumption | 4W (probe run) /1.5W (probe stop) |
| Battery Replaceable | Yes |
| Battery last | 3 -4 hours |
|
|
