Features: 1. Automatic storage of test results, review and print all
parameters in test results;2.Color touch screen, all parameters and histograms can be
displayed in the same screen; 3.Support the expansion of external
devices such as mouse, keyboard and printer; 4.Optical five
reference ranges: newborn, children, adult women, adult men, and
general use; 5.Multiple clogging elimination methods: high-pressure
burning jewel hole, high-pressure reverse rinsing and soaking;
6.Automatic cleaning of sample probe; 7.By VGA interface, external
projector or external display screen can be connected; 8.Chinese
and English system language; 9.Built-in thermal printer, serial
port printing and other printing methods; 10.With quality control
management and calibration management function; 11.Use the
cyanide-free SFT method (environmentally friendly) to measure
hemoglobin; 12.Floating boundary algorithm and histogram abnormal
prompt function. Performance: 1.Test parameters: WBC 3-part differential counting, 23 parameters
(including WBC, RBC, PLT color histogram); 2.Measurement principle:
counting by electrical impedance method, colorimetric method to
measure HGB; 3.Quality control method: L-J, automatic drawing and
printing of quality control charts; 4. Sample volume: trace
detection, 10μL peripheral blood or anticoagulant blood,
pre-dilution mode 20μL; 5.Precision: WBC (white blood cell)
CV≤4.0%, RBC (red blood cell) CV≤2.0%, HGB (hemoglobin) CV≤2.0%,
PLT (platelet) CV≤8.0%, MCV (average red blood cell volume) CV≤3.0%
; 6.Accuracy: the allowable relative deviation range: WBC≤±15%,
RBC≤±6.0%, HGB≤±6.0%, PLT≤±20.0%, HCT (hematocrit)≤±9.0%; 7.Blank
count: WBC≤0.5×109/L, RBC≤0.05×1012/L, HGB≤2.0g/L, PLT≤10.0×109/L;
8.Carry-over: WBC≤3.5%, RBC≤2.0%, HGB≤2.0%, PLT≤5.0%; 9.Linearity
deviation: WBC≤±5%, RBC≤±5%, HGB≤±3%, PLT≤±10%; 10.Related
coefficient: WBC≥0.990, RBC≥0.990, HGB≥0.990, PLT≥0.990;
11.Display: color LCD touch screen; 12.Detection channel: dual
channel; 13.Test speed: 35 (or 60) specimens/hour, continuous
working for 24 hours; 14.Data storage: It can automatically store
more than 30,000 groups of complete results (each result has three
histograms); 15.Interface: RS232 interface, VGA interface; 16.Power
supply: ~100V-240V; 50/60Hz. Accessories: 1.Mouse 2.Thermal print paper 3.Power cord 4.Grounding cable
5.Serial cable 6.Pipe assembly (for Diluent, Hemolytic agent,Waste
liquid respectively) 7.Touch pen 8.User manual 9.Key of device side
board Physical characteristic: Dimension: 433mm(L)×300mm(W)×430mm(H) Weight: 19kg Operating
Environment: Temperature: 18℃~25℃ Relative humidity: ≤80%
Atmospheric pressure: 86.0kPa~106.0kPa Storage Environment:
Temperature: -10℃~55℃ Relative humidity: ≤93% Atmospheric pressure:
50.0kPa~106.0kPa
